20m Ultrasonic Water Depth Sensor 500KHZ Ultrasonic Temperature Sensor

Ask Lasest Price
Brand Name :	TAIMI
Certification :	ISO,RoHS CE
Model Number :	TM-18-500KA
Price :	negotiable
Delivery Time :	10~20days
Payment Terms :	T/T
Supply Ability :	100000/month

Add to Cart

Product Details
Company Profile

20m Ultrasonic Water Depth Sensor 500KHZ Ultrasonic Temperature Sensor

Frueqency:	500KHZ±3%	Material:	PZT4
Parallel Resistance (Minimum):	50±30%(Ω)	Usage:	Underwater Sensor
Working Temperature:	-20~70℃	Case Material:	ABS
IP Level:	IP68
High Light:	fish finder sensor , underwater sensors

20m depth measuring ultrasonic digital temperature sensor for water flow meter

1.Introduction:

The ultrasonic probe is a device to transmit and receive ultrasonic waves in the process of ultrasonic detection.The performance of the probe directly affects the performance of the ultrasonic wave and the detection performance of the ultrasonic wave.

2.Application:

This product specification is suitable for household ultrasonic gas meter

3.Main parameters

No.	item	Parameter
1	frequency(fr)	500KHZ±3%
2	Beam Angle	6°
3	Band width	10%
4	Comprehensive Sensitivity: 0 dB=10 Vp-p; Cycle:10; Distance: 7cm	-34dB min
6	Parallel resistance (Minimum)	50±30%(Ω)
7	Static capacitance(pf)	2000±20%
8	Working Voltage (Maximize) Pluse Wave(duty cycle 2%)	<600V
9	working Temperature	-20~70℃
10	MWP(Maximum working pressure)	1.6MPa
11	Case Material	ABS
12	IP Level	IP68

4.Total resistance - phase curve

5.The sensitivity test

Launch voltage: 10 vp - p; Cycle: 10; Distance: 7 cm

20m Depth Measuring Ultrasonic Digital Temperature Sensor For Water Flow Meter
