Capacitive Ultrasonic Transducer Gasoline Level Digital Ultrasonic Sound Sensor

Ask Lasest Price
Brand Name :	TAIMI
Model Number :	TM-A01 waterproof ultrasonic sensor
Certification :	ISO9001、ISO14001、IATF16949
Price :	negotiable
Payment Terms :	T/T
Supply Ability :	1000000/month
Delivery Time :	10~15days

Add to Cart

Product Details
Company Profile

Capacitive Ultrasonic Transducer Gasoline Level Digital Ultrasonic Sound Sensor

Capacitive Transducer Gasonline Level Digital Low Power Distance Ultrasonic Sound Sensor

Highlights of waterproof Fuel Level Digital ultrasonic sensor:

Wide voltage power input supported.
Multiple output modes
Integrated and open waterproof sensor
Temperature compensation
Strong anti-interference, anti-static abilities
Data output stable and reliable
Tiny size, easy to install
Long measurement range, high accuracy
Automatic output mode, not occupy hardware resources
Controlled output mode, low power consumption

waterproof Fuel Level Digital ultrasonic sensor Basic Parameters:

Items	(A01A serial) For plane distance measurement	(A01B serial) For human body measurement	(A01C serial) For rubbish measurement
Working voltage	DC3.3V- DC5.0V	DC3.3V- DC5.0V	DC3.3V- DC5.0V
Average working current	<10mA	<10mA	<10mA
Blind distance	≤28	≤28	≤28
The measuring range (without horn mouth)	28cm-450cm	28cm-450cm	28cm-450cm
The measuring range (with horn mouth)	28cm-750cm	28cm-750cm	28cm-750cm
Detection Angle (without horn mouth)	-	≈75 Degree	-
Detection Angle (with horn mouth)	≈40 Degree	≈65 Degree	-
Output modes	UART auto output UART controlled output PWM auto output PWM controlled output Digital Output	UART auto output UART controlled output PWM auto output PWM controlled output Digital Output	UART auto output PWM auto output

Waterproof Fuel Level Digital ultrasonic sensor Mechanical Features:

waterproof Fuel Level Digital ultrasonic sensor Specification

Model		TM-A01
Product Name		Integrated waterproof ultrasonic ranger
Highlight		Wide voltage power input supported. Multiple output modes Integrated and open waterproof sensor Temperature compensation Strong anti-interference, anti-static abilities Data output stable and reliable Tiny size, easy to install Long measurement range, high accuracy Automatic output mode, not occupy hardware resources Controlled output mode, low power consumption
Operating Voltage		DC 3.3-5 v
Average Current		<10 mA
Peak Current		<50 mA
Blind Area Distance		28 cm
Measuring Range without bell mouth		A01A 28-450cm / A01B 28-450cm /A01C 28-250cm
Measuring Range with bell mouth		A01A 28-750cm / A01B 28-750cm /A01C 28-250cm
Measuring angle without bell mouth		A01B 75°
Measuring angle with bell mouth		A01A 40° / A01B 65°
Accuracy		10 mm
Output Method		UART auto/UART controlled/PWM controlled/PWM auto/switch
Frequency		40 KHz
Temperature Compensation		Yes

waterproof Fuel Level Digital ultrasonic sensor Applications:

1. Level distance measurement;

2. Liquid level measurement;

3. Parking management system;

4. Intelligent bin management system;

5. Robot obstacle avoidance,automatic control;

6. Detect the objects close to and the existence of external objects

Certificates

waterproof ultrasonic sensor Workshop

waterproof ultrasonic sensor Transport

waterproof ultrasonic sensor FAQ

1. Q: When can we get the reply?

Any inquiries will be replied within 24 hours.

2. Q: Can i have samples?

A: Yes. Sample is surely ok. We can even send you free sample and you should only pay for the freight fee.

3. Q: What about minimum order quantity?

A: We have no limit for MOQ, so you can even buy only 1 piece. Welcome to buy sample to test first.

4. Q: What about delivery time?

A: We will send sample to you within 3 days.

Production for big quantity needs 20 to 25 days. And it also depends on product and quantity.

5. Q: What about terms of payment?

A: Payment terms: T/T, west Union, Paypal and L/C etc.

6. Q: How you will send the goods to us?

A: We will send the goods to you by Air (DHL, Fedex, UPS, TNT) and Sea shipping etc.

7. Q: Are you trading company or manufacturer ?

A: We are in China buzzer manufactory

8. Q: Do you support OEM and ODM services?

A: Yes, surely support. we can customize products according to the drawing.

9. Q: Can you provide driven circuit?

A: Yes, of course sure.

10. Q: Can you solve technical problems for us?

A: Yes, Our Technical team will try our best to support you.
