    14mm 40KHz Waterproof Ultrasonic Sensor

    Ask Lasest Price
    Brand Name : TAIMI
    Model Number : TM-1040H09ATR Waterproof Ultrasonic Transducer
    Certification : ISO,RoHS CE
    Price : negotiable
    Payment Terms : T/T
    Supply Ability : 100000/month
    Delivery Time : 10~20days
    • Product Details
    • Company Profile

    14mm 40KHz Waterproof Ultrasonic Sensor

    Distance Measuring Home Application 14mm 40KHz Waterproof Ultrasonic Transducer Ultrasonic Sensor


    Waterproof Ultrasonic TransducerProduct Description

    Water proof type ultrasonic sensors were widely used for parking sensors, proximity sensors and level sensors, etc. With perfect seal these sensors can be used in a relatively poor environment such as dust and humidity.


    Waterproof Ultrasonic Transducer

    Specification


    1>. Type:Waterproof Ultrasonic Transducer ;
    2>. Diameter:14mm;
    3>. Frequency:40KHz;

    4> Transmitting Sound Pressure Level:?100dB;

    5>. Receive Sensitivity:?-84dB;

    6>. -6dB Directivity(deg):70±10°;

    7>. Ringing(ms):?1.2ms;

    8>. Capacitance(pF):2000±30% at 1.0KHz;

    9>. Allowable Input Voltage(Vp-p):150V(40KHz);

    10>. Operating temperature: -40°C~+80°C;

    11>.Storage temperature:-40°C~+85°C;

    12>.Terminal:Pins;


    Waterproof Ultrasonic Transducer Production details

    Waterproof Ultrasonic Transducer Advantage


    1.Automated machine dispensing,perfect product appearance .
    2.Sound test, using decibels,frequency waveforms, impedance recognition, excellent product sound and good consistency.
    Ultrasonic Sensor Application

    Water proof type ultrasonic sensors were widely used for parking sensors, proximity sensors and level sensors, etc. With perfect seal these sensors can be used in a relatively poor environment such as dust and humidity.


    Main Series



    Why Choose Us


    TaiMi electronics technology Co.,ltd has strong technical R & D team, scientific production platform and strict quality control system. On the road of innovation, we have not been stagnant. We have constantly developed and produced products with beautiful appearance and excellent performance, energy conservation and environmental protection green products, aiming to meet the market demand. Products are widely recognized and trusted by users, and can meet the changing economic and social needs.



    Waterproof Ultrasonic TransducerWorkshop:


    Our Services

    1. Reply your enquiry in 24 working hours.


    2. Experienced staffs answer all your questions in professional and fluent English.


    3. Customized design is available.


    Technical support


    1.We have professional technical support team to support our customers


    2.If you have any question for the technology of our products,please Email to us and we will reply to you immediately


    FAQ


    1. Q: When can we get the reply?
    Any inquiries will be replied within 24 hours.
    2. Q: Can i have samples?
    A: Yes. Sample is surely ok. We can even send you free sample and you should only pay for the freight fee.
    3. Q: What about minimum order quantity?
    A: We have no limit for MOQ, so you can even buy only 1 piece. Welcome to buy sample to test first.
    4. Q: What about delivery time?
    A: We will send sample to you within 3 days.
    Production for big quantity needs 20 to 25 days. And it also depends on product and quantity.
    5. Q: What about terms of payment?
    A: Payment terms: T/T, west Union, Paypal and L/C etc.
    6. Q: How you will send the goods to us?
    A: We will send the goods to you by Air (DHL, Fedex, UPS, TNT) and Sea shipping etc.
    7. Q: Are you trading company or manufacturer ?
    A: We are in China buzzer manufactory
    8. Q: Do you support OEM and ODM services?
    A: Yes, surely support. we can customize products according to the drawing.
    9. Q: Can you provide driven circuit?
    A: Yes, of course sure.
    10. Q: Can you solve technical problems for us?
    A: Yes, Our Technical team will try our best to support you.
