Small Active Piezoelectric Alarm Buzzer 80dB 14mm Alarm Quiz
14mm Active Factory Price System Connector Alarm Quiz Small Piezo
12V Buzzer
TM-1407 12V low current piezo buzzer
| Product: Piezoelectric Buzzers | Sushin Part No:TM-1407 12V low current piezo buzzer |
| Technical Terms |
| Resonant Frequency (KHZ) | 4.0±0.3 |
| Rated Voltage (VP-P) | 12.0 |
| Operating Voltage (VP-P) | 3~15 |
| Max. Current Consumption at Rated Voltage (mA) | 10.0 |
| Min. Sound Output at 10cm at Rated Voltage (dB) | ≥85 |
| Operating Temperature (0C) | -20~+70 |
| Storage Temperature (0C) | -30~+80 |
| Housing Material | PBT(Black) |
Buzzer Soldering process | Soldering Parameter |
| Temp.( 0C) | Time(Sec.) | Times |
| Lead Free | Reflow soldering | 245±15 | above 1800C time 40~70 | 3 |
| Wave soldering | 260±5 | 4~8 | 2~3 |
| Manual soldering | 350±10 | 1~3 | 2~3 |
Classification of buzzer :
1. According to the principle of its driving mode, it can be
divided into: active buzzer (including driving circuit, also called
self-excited buzzer) and passive buzzer (external drive, also
called other excited buzzer) Sounder);
2. According to the different construction methods, it can be
divided into: electromagnetic buzzer and piezoelectric buzzer;
3. According to the different packages, it can be divided into: DIP
BUZZER (Pin Buzzer) and SMD BUZZER (SMD Buzzer);
4. According to the difference of current, it can be divided into:
DC buzzer and AC buzzer. Among them, DC is the most common
piezoelectric buzzer, which uses piezoelectric material, that is,
when the external force causes the piezoelectric material to occur
Piezoelectric materials generate electrical charges during
deformation. Similarly, piezoelectric materials deform when
energized.
The electromagnetic buzzer mainly uses the characteristics of the
conductive conductor to generate a magnetic field, and uses a fixed
permanent magnet and the conductive conductor to generate magnetic
force to push the tympanic membrane fixed on the coil.
Due to the different sounding principles of the two buzzers, the
piezoelectric structure is simple and durable but has a single tone
and color difference. It is suitable for devices such as alarms.
The electromagnetic type is mostly used for voice, music and other
equipment because of its good timbre.
Electromagnetic buzzer Workshop
Electronic Alarm Buzzer Certifications
Transport for BUZZER
8. Piezo Siren FAQ
| 1. Q: When can we get the reply? |
| Any inquiries will be replied within 24 hours. |
| 2. Q: Can i have samples? |
| A: Yes. Sample is surely ok. We can even send you free sample and
you should only pay for the freight fee. |
| 3. Q: What about minimum order quantity? |
| A: We have no limit for MOQ, so you can even buy only 1 piece.
Welcome to buy sample to test first. |
| 4. Q: What about delivery time? |
| A: We will send sample to you within 3 days. |
| Production for big quantity needs 20 to 25 days. And it also
depends on product and quantity. |
| 5. Q: What about terms of payment? |
| A: Payment terms: T/T, west Union, Paypal and L/C etc. |
| 6. Q: How you will send the goods to us? |
| A: We will send the goods to you by Air (DHL, Fedex, UPS, TNT) and
Sea shipping etc. |
| 7. Q: Are you trading company or manufacturer ? |
| A: We are in China buzzer manufactory |
| 8. Q: Do you support OEM and ODM services? |
| A: Yes, surely support. we can customize products according to the
drawing. |
| 9. Q: Can you provide driven circuit? |
| A: Yes, of course sure. |
| 10. Q: Can you solve technical problems for us? |
| A: Yes, Our Technical team will try our best to support you. |
9. Contact Us
10. Other piezo Buzzer Catalogues
TM-1407 12V low current piezo buzzer
