2 PIN CONNECTOR 40kHz AIR TRANSDUCER STEPPED 40khz Transmitter receiver waterproof sensor

Ask Lasest Price
Brand Name :	TaiMI
Model Number :	TM-1640H12ATR-L TRANSDUCER STEPPED 40khz
Certification :	ROHS/REACH
Price :	Negotiable
Payment Terms :	Western Union, MoneyGram, T/T ,PAYPAL
Supply Ability :	10000000/Month
Delivery Time :	2 weeks

Add to Cart

Product Details
Company Profile

2 PIN CONNECTOR 40kHz AIR TRANSDUCER STEPPED 40khz Transmitter receiver waterproof sensor

Example case customer application:

Features

Compact and light weight
High sensitivity and sound pressure
Wide bandwidth & quick response
Stable output over operating temp.range

Diameter 16mm ultrasonic parking sensor for distance 0.2~6m
This specification shall cover the characteristics of the ceramic ultrasonic sensor with Compatible with transmitting and receiving.

Technical parameters
Part number	TM-1640H12ATR-L
Construction	Water proof type
Using method	Dual use
Center frequency	40.0±1.0KHz
Sound pressure level	105dB min.
Sensitivity	-82dB min.
Capacitance	1900Pf±20%
Ringing	1.2ms max.
Maximum input voltage	150Vp-p
Directivity	80°±15° (-6dB)
Operating temperature	-30°C~+70°C
Storage Temperature	-40°C~+80°C

Detailed Images

Please connect us for get more details:
Email:sales88@taimihk.com
WhatsApp/mobile:+86 13538467125

Ultrasonic sensor Ultrasonic piezoelectric ceramic probe 16MM double Angle enclosed sensor 2

Ultrasonic sensor Ultrasonic piezoelectric ceramic probe 16MM double Angle enclosed sensor 3

Waterproof Ultrasonic Transducer Advantage

1.Automated machine dispensing,perfect product appearance .

2.Sound test, using decibels,frequency waveforms, impedance recognition, excellent product sound and good consistency.

FAQ

Q: Delivery Time
A: Based on the order quantity, the goods will be sent out within 2-7 days.

Q: Payment
A: T/T,W esternUnion,L/C,Paypal

Q: Quantity guarantee
A: All products will have been strictly Quality insepected before packing.

Q: Shipping
A: We have strong cooperation with DHL,TNT,UPS,FEDEX,and shipping agent for air and sea.
give the economic freight according to goods weight.

Q: Wealth of experience
A: Professional sercive.choose us,you will do the trade more easily.

Q: Good Service
A: Excellent team to offer the efficient and professional reply.

Q: Technical Problem
A: Provide Professional Technical Support.
